Brand New PAIR Front CV Drive Shaft

***Pair Kit, CVT Only***

Built tough to OEM specifications using heat-treated chrome steel for maximum product life. High-quality Neoprene dust boots and stainless steel clamps help prevent contamination. Packed with moly grease to perform at varying angles and speeds without friction, even at high revolutions.

Vehicle Fitment

• Honda CRV RW1 (06/2017~07/2023) 1.5L Petrol L15BG
• Honda CRV RW2 (06/2017~07/2023) 1.5L Petrol L15BG

⚠️ Important Notes for You:
We strongly advise using the Australian Number Plate lookup to confirm fitment.

Sizing and Specifications

Left CV Shaft

• Length (Compressed): 672 mm
• Spline Count - Outer/Wheel Side: 30
• Spline Count - Inner/Diff Side: 27
• Inboard Joint Type: Tripod
• Outboard Joint Type: Ball
• Drive Shaft Seal (Inner) ID: 40 mm
• Hub Nut: M26 x 1.5

Right CV Shaft

• Length (Compressed): 670 mm
• Spline Count - Outer/Wheel Side: 30
• Spline Count - Inner/Diff Side: 25 + 2 Blank
• Inboard Joint Type: Tripod
• Outboard Joint Type: Ball
• Drive Shaft Seal (Inner) ID: 68 mm
• Hub Nut: M26 x 1.5

What's Included

• 2 x CV Shaft

All components include a 12 month/20,000km warranty and support from our specialist team.
