Brand New Front CV Drive Shaft

***Pair Kit, Automatic Only***

Built tough to OEM specifications using heat-treated chrome steel for maximum product life. High-quality Neoprene dust boots and stainless steel clamps help prevent contamination. Packed with moly grease to perform at varying angles and speeds without friction, even at high revolutions.

Vehicle Fitment

• Kia Stonic YB DA814 (01/2017~05/2024) 1.4L Petrol G4LC
• Kia Stonic YB D6814 (10/2020~05/2024) 1.4L Petrol G4LC

⚠️ Important Notes for You:
We strongly advise using the Australian Number Plate lookup to confirm fitment.

Sizing and Specifications

Left CV Shaft

• Length (Compressed): 667 mm
• Spline Count - Outer/Wheel Side: 25
• Spline Count - Inner/Diff Side: 27
• Outboard Joint Type: Ball
• Inboard Joint Type: Tripod
• Hub Nut: M22 x 1.5

Right CV Shaft

• Length (Compressed): 924 mm
• Spline Count - Outer/Wheel Side: 25
• Spline Count - Inner/Diff Side: 27
• Outboard Joint Type: Ball
• Inboard Joint Type: Tripod
• Hub Nut: M22 x 1.5

What's Included

• 2 x CV Shafts

All components include a 12 month/20,000km warranty and support from our specialist team.
