Front Right Drive Shaft for Suzuki Alto GF FC31S 1.0L K10BN 2009~2015 Automatic

Product image 1

Front Right Drive Shaft for Suzuki Alto GF FC31S 1.0L K10BN 2009~2015 Automatic

Brand New Right Front CV Drive Shaft

***Right Hand Side, Automatic Transmission - Please Compare and Check Before Fitting***

Built tough to OEM specifications using heat-treated chrome steel for maximum product life. High-quality Neoprene dust boots and stainless steel clamps help prevent contamination. Packed with moly grease to perform at varying angles and speeds without friction, even at high revolutions.

Vehicle Fitment

  • Suzuki Alto GF FC31S (07/2009~01/2015) 1.0L Petrol K10BN - Automatic
⚠️ Important Notes for You:
We strongly advise using the Australian Number Plate lookup to confirm fitment.

Sizing and Specifications

    • Length (Compressed): 837 mm
    • Spline Count - Outer/Wheel Side: 23
    • Spline Count - Inner/Diff Side: 22
    • Length (Compressed): 837 mm
    • Spline Count - Outer/Wheel Side: 23
    • Spline Count - Inner/Diff Side: 22
    • Outboard Joint Type: Ball
    • Inboard Joint Type: Tripod
    • Drive Shaft Seal (Inner) ID: 40 mm
    • Hub Nut: M18 x 1.5
    • ABS: Yes
    • ABS Ring Teeth: 43

What's Included

    • 1 x CV Shaft

All components include a 12 month/20,000km warranty and support from our specialist team.
