CV Joint Axle Drive Shaft Left Hand Side Front Sedan & Wagon



Sub Models: Executive, Premium, Elite, Luxury & Touring

Fits:

Diamante & V3000 KR/KS 3.0L 6G72  07/1991-09/1996

Magna TR/TS 3.0L 6G72  04/1991-12/1996

Verada KR/KS 3.0L 6G72  07/1991-09/1996



 The Nitty Gritty

• Length: 616mm
• Spline Count (Wheel Side): 27
• Spline Count - Inner/Diff Side - Female: 26
• Outboard Joint Type: Ball
• Inboard Joint Type: Tripod
• Hub Nut: M22 x 1.5



What You Get

1 x CV Shaft



Built tough to OEM specifications using heat-treated chrome steel; maximising product life. High-quality Neoprene dust boots and stainless steel clamps helps to prevent contamination. Moly grease for working at varying angles and speeds without friction, at high revolutions.



What You Really Get

Our comprehensive range of constant velocity driveshafts is continuing to lead the way in the driveline aftermarket. The excellent performance and quality has resulted in their growing popularity. The range now boasts over 750 individual part numbers, which covers the vast majority of passenger and 4WD applications on Australian roads today. All our CV driveshafts are covered by a 12 month / 20,000 km warranty. Please note: this excludes CV Boots, which are only warranted for 3 months from date of purchase.
